功能點 Feature and functions
●新款面板，三缸雙過濾結構，隨時洗滌淺色衣物的洗凈度要求，手動控制；使用電源為380V/220V。
●關鍵部件為質不銹鋼，軸承采用國內綜合性能好的軸承，德國西門子動力，歐洲風格，外型美觀，性能可靠，經濟實用，可連續洗滌15-20機后蒸餾。
●電腦板VFD圖象化顯示，口徑裝載門投取衣物方便，雙溫控蒸餾安可靠。
●絨毛收集器、紐扣收集器透明設計，減少了溶劑泄露；配有溶劑箱視鏡沖洗功能。
●配置：后部各種閥門均為手動控制，過濾器清洗為電動操作。
●The new panel, three cylinders double filters structure, ready to meet the light colored clothes washing high washing cleanliness requirements, manual control, With a 380 v power supply.
●The key parts are made of high quality stainless steel, bearing with bearing, Germany's Siemens power，comprehensive performance of the best European style, beautiful appearance, reliable performance, economical and practical, continuous washing machine after a 15-20 distillation.
●The computer board VFD image display, large-diameter loading door fetching clothes is convenient, safe and reliable double temperature distillation.
●Fuzz collector, collector buttons unique transparent design, reduce the solvent leaking; with solvent box mirror flushing function.
●Configuration: the valves are manual control, filter cleaning to electric operation. ‘
●新款面板，三缸雙過濾結構，隨時洗滌淺色衣物的洗凈度要求，手動控制；使用電源為380V/220V。
●關鍵部件為質不銹鋼，軸承采用國內綜合性能好的軸承，德國西門子動力，歐洲風格，外型美觀，性能可靠，經濟實用，可連續洗滌15-20機后蒸餾。
●電腦板VFD圖象化顯示，口徑裝載門投取衣物方便，雙溫控蒸餾安可靠。
●絨毛收集器、紐扣收集器透明設計，減少了溶劑泄露；配有溶劑箱視鏡沖洗功能。
●配置：后部各種閥門均為手動控制，過濾器清洗為電動操作。
●The new panel, three cylinders double filters structure, ready to meet the light colored clothes washing high washing cleanliness requirements, manual control, With a 380 v power supply.
●The key parts are made of high quality stainless steel, bearing with bearing, Germany's Siemens power，comprehensive performance of the best European style, beautiful appearance, reliable performance, economical and practical, continuous washing machine after a 15-20 distillation.
●The computer board VFD image display, large-diameter loading door fetching clothes is convenient, safe and reliable double temperature distillation.
●Fuzz collector, collector buttons unique transparent design, reduce the solvent leaking; with solvent box mirror flushing function.
●Configuration: the valves are manual control, filter cleaning to electric operation. ‘
| 型號 model項目 item | ||
| 洗滌容量 | Water Capacity | 8-10kg |
| 洗衣缸尺寸 | Washing Cylinder | 690×400mm |
| 容積載荷比 | Capacity/Load Ratio | 18 /kg |
| 洗滌速度 | Washing Speed | 40 r/min |
| 脫干速度 | Spinning Speed | 400 r/min |
| 油缸1容積 | Oil Cylinder Capacity | 110L |
| 油缸2容積 | No.2 Oil Cylinder Capacity | 110L |
| 油缸3容積 | No.3 Oil Cylinder Capacity | 140L |
| 蒸餾箱容積 | Distillation Tank Capacity | 150L |
| 尼過容積 | Nylon Filter Capacity | 30L |
| 洗滌電機功率 | Power of Washing Motor | 1.5KW |
| 泵功率 | Power of Pump | 0.55KW |
| 風機功率 | Power of Air Blower | 0.75KW |
| 烘干功率 | Power of Drying Heater | 5.4KW |
| 蒸餾功率 | Distillation Power | 7.2KW |
